1
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Infrared
Jpeg, Tif

X-ray & Infrared Images of W44
Also known as G34.7-0.4, W44 is an expanding supernova remnant that is interacting with dense interstellar material that surrounds it. X-rays from Chandra (blue) show that hot gas fills the shell of the supernova remnant as it moves outward. Infrared observations from the Spitzer Space Telescope reveal the shell of the supernova remnant (green) as well as the molecular cloud (red) into which the supernova remnant is moving and the stars in the field of view.
(Credit: X-ray: NASA/CXC/Univ. of Georgia/R.Shelton & NASA/CXC/GSFC/R.Petre; Infrared: NASA/JPL-Caltech)

Fast Facts for W44:
Credit  X-ray: NASA/CXC/Univ. of Georgia/R.Shelton & NASA/CXC/GSFC/R.Petre; Infrared: NASA/JPL-Caltech
Scale  Image is 52 arcmin across (about 126 light years)
Category  Supernovas & Supernova Remnants
Coordinates (J2000)  RA 18h 55m 59.3s | Dec +01 20' 07.0"
Constellation  Aquila
Observation Dates  3 pointings on 31 Oct 2000, 23 and 25 Jun 2005
Observation Time  38 hours 10 min (1 day 14 hours 10 min)
Obs. IDs  1954, 5548, 6312
Instrument  ACIS
References Shelton, R. et al, 2004, ApJ, 611, 906; arXiv:astro-ph/0407026
Color Code  X-ray (Cyan); Infrared (Red, Green, Blue)
Distance Estimate  About 8300 light years

2
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Optical
Jpeg, Tif

X-ray & Optical Images of SN 1987A
First seen in 1987, this supernova (dubbed SN 1987A) was the brightest supernova and nearest one to Earth in the last century. In a supernova explosion, a massive star runs out of fuel then collapses onto their core, flinging the outer layers of the star into space. By combining X-ray data from Chandra (blue) with optical data from the Hubble Space Telescope (appearing orange and red), astronomers can observe the evolution of the expanding shell of hot gas generated by the explosion and watch as a shock wave from the blast heats gas that once surrounded the doomed star. The two bright stars near SN 1987A are not associated with the supernova.
(Credit: X-ray: NASA/CXC/PUS/E.Helder et al; Optical: NASA/STScI)

Fast Facts for Supernova 1987A:
Credit  X-ray: NASA/CXC/PUS/E.Helder et al; Optical: NASA/STScI
Scale  Image is 20 arcsec across (about 14 light years)
Category  Supernovas & Supernova Remnants
Coordinates (J2000)  RA 05h 35m 28.30s | Dec -69 16' 11.10"
Constellation  Dorado
Observation Dates  4 pointings between Jan 2008 and Jan 2009
Observation Time  22 hours 13 min
Obs. IDs  9142, 9143, 9806, 10130
Instrument  ACIS
Also Known As SN 1987A
References Helder, E. et al, 2013, ApJ, 764, 11; arXiv:1212.2664
Color Code  X-ray (Blue); Optical (Red, Green, Blue)
Distance Estimate  About 160,000 light years

3
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Optical
Jpeg, Tif

X-ray & Optical Images of Kes 79
Like SN 1987A, this object, known as Kesteven 79, is the remnant of a supernova explosion, but one that went off thousands of years ago. When massive stars run out of fuel, their cores collapse, generating a shock wave that flings the outer layers of the star into space. An expanding shell of debris and the surviving dense central core are often heated to millions of degrees, and give off X-rays. In this image of Kesteven 79, X-rays detected by Chandra (red, green, and blue) have been combined with an optical image from the Digitized Sky Survey of the field of view that reveals the stars (appearing as white).
(Credit: X-ray: NASA/CXC/SAO/F.Seward et al, Optical: DSS)

Fast Facts for Kes 79:
Credit  X-ray: NASA/CXC/SAO/F.Seward et al, Optical: DSS
Scale  Image is 15.6 arcmin across (about 104 light years)
Category  Supernovas & Supernova Remnants
Coordinates (J2000)  RA 18h 52m 39.00s | Dec +00 40' 00.0''
Constellation  Aquila
Observation Dates  31 Jul 2001
Observation Time  8 hours 13 min
Obs. IDs  1982
Instrument  ACIS
References Sun, M. et al, 2004, ApJ, 605, 742; arXiv:astro-ph/0401165
Color Code  X-ray (Red, Green, Blue); Optical (Red, Green, Blue)
Distance Estimate  About 23,000 light years

4
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Optical
Jpeg, Tif
Click for large jpg Radio
Jpeg, Tif

X-ray, Optical & Radio Images of MS 0735.6+7421
The galaxy cluster MS 0735.6+7421 is home to one of the most powerful eruptions ever observed. X-rays detected by Chandra (blue) show the hot gas that comprises much of the mass of this enormous object. Within the Chandra data, holes, or cavities, can be seen. These cavities were created by an outburst from a supermassive black hole at the center of the cluster, which ejected the enormous jets detected in radio waves (pink) detected the Very Large Array. These data have been combined with optical data from Hubble of galaxies in the cluster and stars in the field of view (orange).
(Credit: X-ray: NASA/CXC/Univ. of Waterloo/A.Vantyghem et al; Optical: NASA/STScI; Radio: NRAO/VLA)

Fast Facts for MS 0735.6+7421:
Credit  X-ray: NASA/CXC/Univ. of Waterloo/A.Vantyghem et al; Optical: NASA/STScI; Radio: NRAO/VLA
Scale  Image is 3 arcmin across (about 2 million light years)
Category  Groups & Clusters of Galaxies
Coordinates (J2000)  RA 07h 41m 50.20s | Dec +74° 14' 51.00"
Constellation  Camelopardalis
Observation Dates  8 pointings between Nov 2003 and Jul 2009
Observation Time  144 hours (6 days 47 min)
Obs. IDs  4197, 10468, 10469, 10470, 10471, 10822, 10918, 10922
Instrument  ACIS
References Vantyghem, A. et al, 2014, MNRAS, 442, 3192; arXiv:1405.6208
Color Code  X-ray: Blue; Optical: Gold; Radio: Pink
Distance Estimate  About 2.6 billion light years (z = 0.216)

5
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Optical
Jpeg, Tif

X-ray & Optical Images of 3C295
The vast cloud of 50-million-degree gas that pervades the galaxy cluster 3C295 is only visible with an X-ray telescope like Chandra. This composite image shows the superheated gas, detected by Chandra (pink), which has a mass equal to that of a thousand galaxies. Hubble's optical data (yellow) reveal some of the individual galaxies in the cluster. Galaxy clusters like 3C295 also contain large amounts of dark matter, which holds the hot gas and galaxies together. The total mass of the dark matter needed is typically five times as great as the gas and galaxies combined.
(Credit: X-ray: NASA/CXC/Cambridge/S.Allen et al; Optical: NASA/STScI)

Fast Facts for 3C295:
Credit  X-ray: NASA/CXC/Cambridge/S.Allen et al; Optical: NASA/STScI
Scale  Image is 1.5 arcmin across (about 1.7 million light years)
Category  Groups & Clusters of Galaxies
Coordinates (J2000)  RA 14h 11m 20s | Dec -52 12' 21
Constellation  Boötes
Observation Dates  2 pointings on 30 Aug 1999 and 18 May 2001
Observation Time  33 hours 20 min (1 day 9 hours 20 min)
Obs. IDs  578, 2254
Instrument  ACIS
Also Known As Cl 1409+524
References Allen, S. et al, 2001, MNRAS, 324, 842; arXiv:astro-ph/0101162
Color Code  X-ray: Purple; Optical: Yellow
Distance Estimate  About 4.7 billion light years (z=0.464)

6
Click for large jpg Composite
Jpeg, Tif
Click for large jpg X-ray
Jpeg, Tif
Click for large jpg Optical
Jpeg, Tif

X-ray & Optical Images of Guitar Nebula
The pulsar B2224+65 is moving through space very rapidly. Because of its high speed, the pulsar is creating a bow shock in its wake. This structure is known as the Guitar Nebula and the likeness of the musical instrument can be seen in the optical data (blue) of this composite image taken by Hubble and the Palomar Observatory. X-ray data from Chandra (pink) reveal a long jet that is coincident with the location of the pulsar at the tip of the "guitar," but is not aligned with its direction of motion. Astronomers will continue to study this system to determine the nature of this X-ray jet.
(Credit: X-ray: NASA/CXC/UMass/S.Johnson et al, Optical: NASA/STScI & Palomar Observatory 5-m Hale Telescope)

Fast Facts for Guitar Nebula:
Credit  X-ray: NASA/CXC/UMass/S.Johnson et al, Optical: NASA/STScI & Palomar Observatory 5-m Hale Telescope
Scale  Image is 3.3 arcmin across (about 5 light years)
Category  Neutron Stars/X-ray Binaries
Coordinates (J2000)  RA 22h 25m 52.36s | Dec +65 35' 33.79''
Constellation  Cepheus
Observation Dates  6 pointings between Oct 2000 and Aug 2012
Observation Time  54 hours (2 days 6 hours)
Obs. IDs  755, 6691, 7400, 13771, 14353, 14467
Instrument  ACIS
References Johnson, S. et al, 2010, MNRAS, 408, 1216; arXiv:1003.1724
Color Code  X-ray (Pink); Optical (Blue)
Distance Estimate  About 4900 light years
