B1957+20:
A Cocoon Found Inside the Black Widow’s Web


B1957+20
Credit: X-ray: NASA/CXC/ASTRON/B.Stappers et al.; Optical: AAO/J.Bland-Hawthorn & H.Jones

This composite X-ray (red/white) and optical (green/blue) image reveals an elongated cloud, or cocoon, of high-energy particles flowing behind the rapidly rotating pulsar, B1957+20 (white point-like source). The pulsar, a.k.a. the "Black Widow" pulsar, is moving through the galaxy at a speed of almost a million kilometers per hour. A bow shock wave due to this motion is visible to optical telescopes, shown in this image as the greenish crescent shape. The pressure behind the bow shock creates a second shock wave that sweeps the cloud of high-energy particles back from the pulsar to form the cocoon.

The Black Widow pulsar is emitting intense high-energy radiation that appears to be destroying a companion star through evaporation. It is one of a class of extremely rapid rotating neutron stars called millisecond pulsars.

These objects are thought to be very old neutron stars that have been spun up to rapid rotation rates with millisecond periods by pulling material off their companions. The steady push of the infalling matter on the neutron star spins it up in much the same way as pushing on a merry-go-round causes it to rotate faster.

The advanced age, very rapid rotation rate, and relatively low magnetic field of millisecond pulsars put them in a separate class from young pulsars, such as the Crab Nebula. Yet the Chandra data show that this billion-year-old rejuvenated pulsar is an extremely efficient generator of matter and antimatter particles, just like its younger cousins.

The key is the rapid rotation of B1957+20. The Chandra result confirms the theory that even a relatively weakly magnetized neutron star can generate intense electromagnetic forces and accelerate particles to high energies to create a pulsar wind, if it is rotating rapidly enough.

Fast Facts for B1957+20:
Credit  X-ray: NASA/CXC/ASTRON/B.Stappers et al.; Optical: AAO/J.Bland-Hawthorn & H.Jones
Scale  Image is 1.2 arcmin per side
Category  Neutron Stars/X-ray Binaries
Coordinates (J2000)  RA 19h 59m 36.80s | Dec +20° 48’ 15.10"
Constellation  Sagitta
Observation Dates  June 21, 2001
Observation Time  12 hours
Obs. IDs  1911
Color Code  Energy (X-ray = red & white; Optical = blue & green)
Instrument  ACIS
Distance Estimate  5,000 light years
Release Date  February 27, 2003
